Features |
Model |
|
EBA20Ⅱ |
|
Power |
|
Electric |
|
|
Operation mode |
|
Laser navigation |
|
|
Rated load capacity |
Q(kg) |
2000 |
|
|
Load center distance |
C(mm) |
600 |
|
|
Carrying distance |
X(mm) |
900 |
|
|
Wheelbase |
Y(mm) |
1120 |
|
|
Weight |
Weight with battery |
kg |
600 |
|
Wheel |
Wheel type，F/R |
|
PU/PU |
|
Front wheel specification |
∅×w(mm) |
Φ80x80 |
|
|
Rear wheel specification |
∅×w(mm) |
Φ230x75 |
|
|
Balance wheel specifications |
∅×w(mm) |
Φ80x35 |
|
|
Tire quantity（drive， balance/load）（X=drive） |
|
1X,4/4 |
|
|
Front wheel track, drive end |
b10(mm) |
648 |
|
|
Rear wheel track, load end |
b11(mm) |
440 |
|
|
Dimensions |
Mast height, extended |
h1(mm) |
205 |
|
Fork height from ground（±5） |
h13(mm) |
85 |
|
|
Body length（safety edge） |
l1(mm) |
1650 |
|
|
Body length（excl. fork，safety edge） |
l2(mm) |
370 |
|
|
Body width（safety edge） |
b1(mm) |
990 |
|
|
Body heigh（twith navigation device） |
h(mm） |
1927 |
|
|
Fork size |
s/e/l(mm) |
60/180/1220 |
|
|
Fork outer width |
b5(mm） |
620 |
|
|
Minimum ground clearance |
m2(mm) |
30 |
|
|
Stacker channel width， pallet 1000×1200（C600) |
Ast(mm) |
1918+300 |
|
|
Stacker channel width， pallet 800×1200（C600) |
Ast(mm) |
1835+300 |
|
|
Minimum turning radius |
Wa(mm) |
1335 |
